Parameter
HDMI protocol: HDMI 1.4
Maximum supported resolution: 1920X1080@60 Hz
Interface: HDMI A interface
Impedance: 100 Ω
Output: HDMI (synchronous audio and video output)
Encoding format: H.264
WIFI:5G
Protocol: Standard 802.11 a/b/g/n
Transmission distance: up to 50 meters in open environments
Power supply: USB power supply: 5 V/2A
Maximum power consumption: MAX 3W
Working temperature/humidity: 0 ℃~50 ℃/10%~80% RH (non solidifying)
Product size: 49.6 × 43.6 × 16.6mm
Resolution: 1920 * 1080, 1280 * 720 (60P), 1280 * 960, 1280 * 800, 1280 * 720 (50P), 1024 * 76
Frame rate: 30-60 frames per second
Delay: 80-100ms (open environment)

RX
Storage space: 128MB
Reception: Built in antenna
Interface: HDMI、USB-C

TX
Number of interfaces: 2
Interface: USB-C
Resolution: 1080P

Function
It can realize the use of laptops, tablets or mobile phones on LCD displays, projectors, touch all-in-one machines
Wireless screen mirroring is performed on display devices such as LED splicing screens.
